Description

Product main features and uses:

This machine can undertake a variety of turning workpiece, it can turning the various parts of the outer circle, inner hole, end and metric thread, Whitworth, module thread and pitch diameter of the thread forming surface; in addition, you can also meet drilling, every hole, sets and other materials process requirements. It can also be used in hard cutting tool for powerful cutting, processing a variety of ferrous and non-ferrous metals.

The width of the side wall of the double bed ribs, inner ribs with box and diagonal reinforcement integral bed structure, high integral rigidity.

Product main technical specification:

Item	Specifications	Unit	CK61125G	CK61140G	CK61160G	CK61180G	CK61200G
Technical specification	Max.swing over bed	mm	1250	1400	1600	1800	2000
	Max.swing over cross slide	mm	800	1000	1200	1400	1600
	Max.turning length	mm	2000-12000
	Bed width	mm	1100
	Max.work piece weight	T	10(15)
Main drive	Form		4 step variable speed
	Range of spindle speeds	R/min	4-500
	Terminal structure		A2-15
	Hole diameter of Spindle	mm	130(145)
	Spindle hole fore-end taper		Metric 120 1:20
	Model of main motor		YVP180L-4-22KW(30kw optional)
Feeding system	Z axis transmission		Ball screw(6m and shorter)
	x axis transmission	mm	Ball screw
	Setting accuracy	mm	X:0.02 ,Z:0.05
	Resetting accuracy	mm	X:0.012 ,Z:0.025
	Slide fast moving speed	Mm/min	4000
Turret	Max.cross travel of carriage	mm	760
	Max. travel of compound side	mm	300
	Length of section of knife handle	mm	45x45
Tailstock	Sleeve diameter of tailstock	mm	260
	Sleeve travel of tailstock	mm	300
	Cone hole taper tailstock’s sleeve	Morse	Metric 80 1:20
	Main motor power	kw	AC 30kw(AC37KW)
Size	LWH	mm	6800X2100X2340(4000MM)
weight	N.G	KG	22000(4000mm)
