Application:
Machine can automatically process the inside cylinder surface, cone surface, circular arc surface, end face, such as processing, and also can process the single and multiple threads in metric, inch and other standards.
Features:
1. A high strength, widening the carriage, suitable for heavy cutting
2.Four station electric tool post
3. Frequency conversion stepless speed regulation
4. Standard configuration: manual chuck
5. Optional configuration: hydraulic chuck
Product main technical specifications:
| Specifications | Units | CAK6150V | CAK6160V |
| Max.swing over bed | mm | 500 | 600 |
| Max.swing over cross slide | mm | 280 | 395 |
| Max.processing length | mm | 1000/1500 | 1000/1500 |
| X/Z axis travel | mm | X:300 Z:1000/1600 | X:300 Z:1000/1600 |
| Spindle nose | A2-8/11 | A2-8/11 | |
| Spindle bore | mm | 82 | 82/130(optional) |
| Bar capacity | mm | 65 | 65/120 |
| Max. spindle speed | rpm | 1800 | 1600/800 |
| Chuck size | mm | 250 | 250/380 |
| Spindle motor | KW | 7.5 | 11 |
| X/Z axis repeatability | mm | ±0.005 | ±0.005 |
| X/Z axis feed motor torque | N.m | 5/7.5（1 m）7.5/10（1.5m） | 5/7.5（1 m）7.5/10（1.5m） |
| X/Z axis rapid traverse | m/min | 8/10 | 8/10 |
| Tailstock sleeve dia. | mm | 75 | 75 |
| Tailstock sleeve travel | mm | 200 | 200 |
| Tailstock sleeve taper | # | MT5 | MT5 |
| Tool post type | 4 station electric tool post | 4 station electric tool post | |
| Cutting tool shape size | mm | 25x25 | 25x25 |
| Guide form | Flat bed | Flat bed | |
| Total power capacity | KVA | 13 | 15 |
| Machine dimension(LxWxH) | mm | 2950/3630x1520x1750 | 2950/3610x1520x1820 |
| Net weight | kg | 2850 | 3150 |
