Specification:
Specification | units | CK5225×H/20 |
Max,turning diameter | mm | 2500 |
Table diameter | mm | 2250 |
Max,height of workpiece | mm | 1600/2000 |
Max.weight of workpiece | t | 20 |
Max.torque of table | KN.m | 63 |
Spindle speed range | r/min | 2-63 |
Max.cutting force of rail head | KN | 30 |
Range of tool feed | mm/min | 0.2-145 |
Horizontal tool travel | mm | 1400 |
Vertrical tool travel | mm | 1000 |
Tool head srapid traverse | mm/min | 3500 |
Tool size | mm | 40×50 |
Main motor power | KW | 55 |
Overall dimension | cm | 540×470×480/520 |
Machine weight(Approx.) | t | 34/36 |
