Specification:
Specification | units | CK5232×H/20 |
Max,turning diameter | mm | 3200 |
Table diameter | mm | 2500 |
Max,height of workpiece | mm | 2000/2500 |
Max.weight of workpiece | t | 20 |
Max.torque of table | KN.m | 63 |
Spindle speed range | r/min | 2-63 |
Max.cutting force of rail head | KN | 35 |
Range of tool feed | mm/min | 0.2-145 |
Horizontal tool travel | mm | 1750 |
Vertrical tool travel | mm | 1250 |
Tool head srapid traverse | mm/min | 3500 |
Tool size | mm | 40×50 |
Main motor power | KW | 55 |
Overall dimension | cm | 610×480x520/570 |
Machine weight(Approx.) | t | 38/40 |
