Specification:
Specification | units | CK5240×H/20 | CK5240×H/32 |
Max,turning diameter | mm | 4000 | |
Table diameter | mm | 2830 | 3200 |
Max,height of workpiece | mm | 2000/2500 | |
Max.weight of workpiece | t | 20 | 32 |
Max.torque of table | KN.m | 63 | 70 |
Spindle speed range | r/min | 2-63 | 0.42-42 |
Max.cutting force of rail head | KN | 35 | 40 |
Range of tool feed | mm/min | 0.2-145 | 0.2-145 |
Horizontal tool travel | mm | 2150 | |
Vertrical tool travel | mm | 1250 | |
Tool head srapid traverse | mm/min | 3500 | 3500 |
Tool size | mm | 40×50 | 50×50 |
Main motor power | KW | 55 | 75 |
Overall dimension | cm | 690×510×640/690 | 690×550×640/690 |
Machine weight(Approx.) | t | 44/46 | 51/52 |
