Specification:
Specification | units | CK5250×H/40 | CK5250×H/65 |
Max,turning diameter | mm | 5000 | |
Table diameter | mm | 4000 | 4500 |
Max,height of workpiece | mm | 2500/3150 | |
Max.weight of workpiece | t | 40 | 65 |
Max.torque of table | KN.m | 80 | 100 |
Spindle speed range | r/min | 0.42-42 | 0.42-42 |
Max.cutting force of rail head | KN | 50 | 60 |
Range of tool feed | mm/min | 0.2-145 | 0.2-145 |
Horizontal tool travel | mm | 2765 | |
Vertrical tool travel | mm | 1250/1600 | |
Tool head srapid traverse | mm/min | 3500 | 3500 |
Tool size | mm | 50×50 | 50×50 |
Main motor power | KW | 75 | 90 |
Overall dimension | cm | 1000×650x710/840 | 1000×700×723/853 |
Machine weight(Approx.) | t | 64/66 | 81/84 |
