Specification:
SPECIFICATIONS | Units | CAK6140V |
Swing over bed | mm | 500 |
Swing over cross slide | mm | 250 |
Distance between centers | mm | 1000/1500/2000/3000 |
Spindle bore | mm | 82 (Opt. 130) |
Spindle bore taper | - | Metric 90/1:20 |
Spindle nose type | - | A2-8(Opt.A2-11) |
Spindle speed steps | - | Stepless |
Spindle speed range | rpm | 1800 (Opt. 800) |
Turret/tool post | - | Electric 4 position |
Tool size | mm | 25*25 |
X axis travel | mm | 250 |
Z axis travel | mm | 1000/1500/2000/3000 |
X axis rapid traverse | mm/min | 6000 |
Z axis rapid traverse | mm/min | 8000 |
Tailstock quill diameter | mm | 75 |
Tailstock quill taper | - | MT5 |
Tailstock quill travel | mm | 150 |
Main motor power | kw | 7.5 |
Coolant motor power | kw | 0.125 |
Weight for 1000 | kg | 2900 |
Weight for 1500 | kg | 3300 |
Weight for 2000 | kg | 3700 |
Dimension for 1000 | mm | 2950*1700*1800 |
Dimension for 1500 | mm | 3650*1700*1800 |
Dimension for 2000 | mm | 4250*1700*1800 |
