Specification:
SPECIFICATIONS | Units | GMC2514 |
Table size（W*L） | mm | 1200x2600 |
X axis travel | mm | 2500 |
Y axis travel | mm | 1500 |
Z axis travel | mm | 800 |
Gantry width/passing height | mm | W：1500 / H：1030 |
Table load | t | 4.5 |
Distance between spindle nose and table surface | mm | 150-950 |
T slot(number-width*pitch) | - | 7-22*170 |
Spindle taper | - | BT50/190 |
Spindle speed | r/min | 6000 |
Rapid traverse speed | m/min | 15 |
Cutting feed speed | m/min | 10 |
Main motor power | kw | 15/18.5 |
Tool magazine | Arm 24 | |
Positioning accuracy | mm | X/Y ±0.0075 Z ±0.015 |
Repeat positioning accuracy | mm | ±0.005 |
Overall dimension | mm | 7700x4200x4200 |
Machine weight(about) | t | 19.5 |
