Product main technical specifications:
Specifications | Units | X6128 | X6032 |
Table size | mm | 1200×280 | 1500x320 |
Table travel | mm | 680/280/400 | 800/300/400 |
T slot(number-width-pitch) | mm | 5-14-50 | 3-16-70 |
Spindle taper | IS040 7:24 | IS040 7:24 | |
Spindle speed range | rpm | 40-1300 (12 steps) | 40-1300 (12 steps) |
Distance between spindle axis and table surface | mm | 0-400 | 0-400 |
Main motor power | kw | 3 | 3 |
Weight | kg | 1300 | 2050 |
Overall dimension | mm | 1725×1450×1750 | 2070x1900x1850 |
