Product main technical Specifications:
Specifications | Units | XA7150 |
Table size | mm | 2000x400 |
Table stroke（X.Y） | mm | 1500x500 |
Vertical travel of headstock | mm | 100-650 |
T-type slot numbers / width /space | mm | 3-18-100 |
Max. load working table | KG | 2000 |
Feed speed | mm/min | 20-2000 |
Rapid feed speed | mm/min | 3500 |
Spindle speed range | rpm | 66-1440 |
Spindle speed step | steps | 12 |
Distance from spindle axis to column guide way | mm | 600 |
Spindle motor power | KW | 7.5 |
Overall dimensions | mm | 3000x2285x2340 |
Machine weight | KG | 5000 |
