The main performance characteristics：
1. Two speed motor, two speed selection;
2. Hydraulic clamp;
3. Saw bow or so gyration;
4. Electric cooling system;
5. Saw bow rotary shaft use a conical bearing, to maintain the accuracy of sawing;
6. Saw blade off discon machine automatically cut off power, protect the safety of the operator
Application：
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
Product main technical parameters:
Main technical parameters | BS-460G | ||
Machining capacity | @90°Round steel | 330mm(13″) | |
@90°Square steel | 460×250mm(18″×9.8″) | ||
@60°Round steel | 205mm(8″) | ||
@60°Square steel | 205×250mm(8″×9.8″) | ||
@45°Round steel | 305mm(12″) | ||
@45°Square steel | 305×250mm(12″×9.8″) | ||
Saw cutting speeds | @ 50HZ | 40/80MPM | |
@ 60HZ | 48/96MPM | ||
Saw blade size | 27x0.9x3960 mm | ||
Motor power | 1.5/2.2kW | ||
Drive | Gear | ||
Package size | 231×107×163cm | ||
NW/GW | 750/830kg | ||
