Features：
extra rigid saw frame design ensures excellent angular accuracy and low vibration when cutting workpieces with very large diameters;
The material support surface features driven feed rollers with extremely high-load capacity ,suitable for very heavy workpiece;
Saw frame lifting adopted double oil cylinder control ,ensuring smooth working;
The heavy saw blade tensioning reduces the workload and helps prevent inaccuracies and premature wear of the saw blade;
One bi-metallic band saw blade and feed roller table are included
Product main technical specifications:
Model | Units | GH42100 | |
Cutting capability | Circular | mm | 1000 |
Rectangular | mm | 1000x1000 | |
Blade speed | m/min | 27、45、69 | |
Blade size | mm | 9820*67*1.6 | |
Main motor power | kw | 11 | |
Hydraulic motor power | kw | 3.75 | |
Coolant pump（w） | w | 125 | |
Work clamping method | - | Hydraulic vise | |
Machine weight | kg | 10000 | |
Overall dimension | mm | 4600*2000*2550/2300*450*700 | |
Package Size | mm | 4600*2000*2550/2300*450*700 | |
