Features：
Solid steel saw frame within a dual-column frame guide
Flat and low profile for easier handling of heavy or large workpiece
Feed of the saw frame is infinitely variable via a hydraulic throttle valve
adjustable saw blade guide ensures good cutting result at any workpiece diameter
Hydraulic workpiece clamping included
Standard equipment :
hydraulic workpiece clamping ,1 saw blade belt ,
material support stand ,coolant system ,work lamp ,operation manual
Optional equipment :
automatic blade breakage control ,fast drop protection devise
,hydraulic blade tension ,automatic chip removal device ,various blade linear speed
,blade protection covers ,wheel cover opening protection ,Ce standard electrical equipment .
Product main technical specifications:
| Specifications | GH4260 | ||
| Sawing range | Round steel | Φ600mm | |
| Square material | 600×600mm | ||
| Belt saw blade size | 6500x41x1.3mm | ||
| Saw blade speed | 27\45\69m/min | ||
| Motor power | Main motor | 5.5kw | |
| Oil pump motor | 0.75kw | ||
| Cooling pump motor | 0.09kw | ||
| Overall dimension | 3200x1500x2000mm | ||
| Weight | 2200kg | ||
