Product main technical specifications:
Model | Units | GHS4235 | |
Cutting capability | Circular | mm | 350 |
Rectangular | mm | 350x350 | |
Blade speed | m/min | 27、45、69 | |
Blade size | mm | 4115*34*1.1 | |
Main motor power | kw | 4 | |
Hydraulic motor power | kw | 0.75 | |
Coolant pump（w） | w | 40 | |
Work clamping method | - | Hydraulic automatic | |
Machine weight | kg | 1600KG | |
Overall dimension | mm | 2000*2350*1600 | |
Package Size | mm | 2200*2450*1600 | |
