Product main technical specifications:
Model | Units | GHSZ4240 | |
Cutting capability | 0° | mm | 550X400 |
45° | mm | 300x400 | |
Blade speed | m/min | 27、45、69 | |
Blade size | mm | 5400*41*1.3 | |
Main motor power | kw | 4 | |
Hydraulic motor power | kw | 1.5 | |
Coolant pump（w） | w | 125 | |
Work clamping method | - | Hydraulic vise | |
Machine weight | kg | 2600 | |
Overall dimension | mm | 2400*2600*2000 | |
Package Size | mm | 2300*3300*2200 | |
